OEM USB Camera Module ov5648 1080P USB Camera Module 500W Camera Module wide angle USB camera
Product Parameter
| Module Specification: | YXF-QQSJ-8809-V1-70AF |
| Module Size: | 62mm * 9mm |
| Module Brands: | YXF |
| View Angle: | 70 ° |
| Focal Length (EFL): | 3.37MM |
| Aperture (F / NO)： | 2.8 |
| Distortion: | <1% |
| Chip Type: | OV5648 |
| Chip Brands: | OmniVision |
| Interface Type： | USB2.0 |
| Active Array Size: | 5000,000 pixels 2592*1944 |
| Lens Size: | 1/4 inch |
| Core Voltage (DVDD) | 1.5V ± 5% (with embedded 1.5V regulator) |
| Analog circuit voltage (AVDD) | 2.6 ~ 3.0V (2.8V typical) |
| Interface Circuit Voltage (DOVDD) (I/O) | 1.7 ~ 3.0V |
| Module PDF | Please contact us. |
| Chip PDF | Please contact us. |
|
Module Size
|
9MM*62MM*5.56MM
|
|
Focus
|
Fix
|
|
Object distance
|
60CM
|
|
PCB printing ink
|
Black
|
|
Assembly technique
|
SMT(ROSH)
|
|
Interface type
|
USB2.0
|
|
Power Supply
|
5V
|
|
Operating system request
|
Windows XP or 7 or 8 or 10 or Androd
|
|
Package
|
Anti-electrostatic tray
|
|
Sensor Type
|
OV5648 1/4”
|
|
Active Array Size
|
2592H*1944H
|
5mp Auto Focus HD Face Recognition Wide-Angle USB Camera With OV5648
We Professional produce CIF, VGA, 2million,3 million, 5 million, 8 million, 12 million, 16 million, 21 million, 22 million, 23 million,24 million pixel camera module. We also could do according to customer's specific requirements.
The CMOS Camera Module has very compact size and is widely applied in Mobile phone, Artificial Intelligence,uav drone,smart home,Iris recognization,Gesture Recognition,Machine Vision,3D printer camera solution,2D Barcode Recognition,Optical Imaging System,Infrared Imagers for Industry,Digital Still Camera, DV, PDA/Handheld, smart toy, PC Camera, Security Camera, Automotive Camera, etc.
We use OVT sensor, Aptina sensor, Samsung sensor, Panasonic sensor, SONY sensor and some snesors which are made in China. Also we have SMT lines, CSP lines and COB lines.
2. Unbeatable Price: We always ensure high price performance to benefit our customers.
3. Excellent Service:We treat clients as friend and aims at building long term business relatiionship.Please call us and look forward to cooperating with you.
Product Details
Feature:
*5MP WDR Non Distortion Auto Focus Lens USB Camera Module
*Widely use for High-speed Scanner / Laptop / All-in-one Machine / Notebooks / Medical Equipment / Bar code scanner
*High quality image
*Low power consumption
*USB2.0 Plug and play
*OTG support,UVC compliance for use in OS Windows,Linux,Android,Mac
