Description
128KB -40℃~+85℃ 2V~3.6V 1@x6ch/16bit ARM Cortex-M3 Full-speed USB Device 2@x16ch/12bit 2 20KB 3 3 Internal oscillator included 72MHz 1 4MHz~16MHz 3 51 LQFP-64 Microcontroller Units (MCUs/MPUs/SOCs) ROHS
Specifications: | |
Attribute | Value |
Category | Embedded Processors & Controllers/Microcontroller Units (MCUs/MPUs/SOCs) |
Datasheet | Geehy APM32F103RBT6 |
RoHS | |
Program FLASH Size | 128KB |
Operating Temperature Range | -40℃~+85℃ |
Supply Voltage Range | 2V~3.6V |
Peripherals / Functions / Protocol Stacks | Low-VoltageDetect;WDT;CCP capture/compare;LIN(Local Interconnect Network);On-chip temperature sensor;IrDA;CRC;DMA;Real-Time Clock |
(E)PWM (Units/Channels/bits) | 1@x6ch/16bit |
CPU Core | ARM Cortex-M3 |
USB (H/D/OTG) | Full-speed USB Device |
DAC (Units/Channels/bits) | - |
ADC (Units/Channels/bits) | 2@x16ch/12bit |
I2C Number | 2 |
RAM Size | 20KB |
U(S)ART Number | 3 |
CMP Number | - |
32Bit Timer Number | - |
16Bit Timer Number | 3 |
8Bit Timer Number | - |
Internal Oscillator | Internal oscillator included |
Maximum Frequency | 72MHz |
CAN Number | 1 |
External Clock Frequency Rang | 4MHz~16MHz |
(Q)SPI Number | 3 |
GPIO Ports Number | 51 |
I2S Number | - |
