Description
The SAMA5D2 System-In-Package (SIP) integrates the Arm® Cortex®-A5 processor-based SAMA5D2 MPU with up to 1 Gbit DDR2-SDRAM or up to 2 Gbit LPDDR2-SDRAM in a single package. By combining the high-performance, ultra-low power SAMA5D2 with LPDDR2/DDR2-SDRAM in a single package, PCB routing complexity, area and number of layers is reduced in the majority of cases. This makes board design easier and more robust by facilitating design for EMI, ESD and signal integrity.
Specifications: | |
Attribute | Value |
Category | Integrated Circuits (ICs) |
Embedded - Microprocessors | |
Mfr | Microchip Technology |
Series | SAMA5D2 |
Package | Tray |
Part Status | Active |
Core Processor | ARM® Cortex®-A5 |
Number of Cores/Bus Width | 1 Core, 32-Bit |
Speed | 500MHz |
Co-Processors/DSP | Multimedia; NEON™ MPE |
RAM Controllers | LPDDR1, LPDDR2, LPDDR3, DDR2, DDR3, DDR3L, QSPI |
Graphics Acceleration | Yes |
Display & Interface Controllers | Keyboard, LCD, Touchscreen |
Ethernet | 10/100Mbps (1) |
SATA | - |
USB | USB 2.0 + HSIC |
Voltage - I/O | 3.3V |
Operating Temperature | -40°C ~ 85°C (TA) |
Security Features | ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC |
Package / Case | 289-TFBGA |
Supplier Device Package | 289-TFBGA (14x14) |
Additional Interfaces | I²C, SMC, SPI, UART, USART, QSPI |
Base Product Number | ATSAMA5 |
