Description
The Texas Instruments MSP430™ family of ultralow-power microcontrollers consists of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low-power modes, is optimized to achieve extended battery life in portable measurement applications. The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 1 µs. The MSP430G2x01 and MSP430G2x11 series is an ultralow-power mixed signal microcontroller with a built-in 16-bit timer and ten I/O pins. The MSP430G2x11 family members have a versatile analog comparator. For configuration details see Table 1. Typical applications include low-cost sensor systems that capture analog signals, convert them to digital values, and then process the data for display or for transmission to a host system.
Specifications: | |
Attribute | Value |
Category | Integrated Circuits (ICs) |
Embedded - Microcontrollers | |
Mfr | Texas Instruments |
Series | MSP430G2xx |
Package | Tape & Reel (TR) |
Cut Tape (CT) | |
Digi-Reel® | |
Part Status | Active |
Core Processor | MSP430 |
Core Size | 16-Bit |
Speed | 16MHz |
Connectivity | - |
Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
Number of I/O | 10 |
Program Memory Size | 512B (512 x 8) |
Program Memory Type | FLASH |
EEPROM Size | - |
RAM Size | 128 x 8 |
Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
Data Converters | - |
Oscillator Type | Internal |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
Supplier Device Package | 14-TSSOP |
Base Product Number | 430G2001 |
