The OV9712 camera module has a wide angle of 166 degrees. Smart home monitoring module small sports DV cable module

Short Description:


Product Detail

Product Tags

Product Parameter

Module Specification: YXF-HDF12-A98-166
Module Size: 8mm * 8mm *98mm
Module Brands: YXF
View Angle: 166 °
Focal Length (EFL): 1.7MM
Aperture (F / NO): TBD
Distortion: <-85.32%
Chip Type: OV9712
Chip Brands: OmniVision
Interface Type: DVP
Active Array Size: 1000,000 pixels  1280*800
Lens Size: 1/4 inch
Core Voltage (DVDD) 1.5V±5%(with embedded 1.5 V regulator)
Analog circuit voltage (AVDD) 3.0 ~ 3.6V±5%V
Interface Circuit Voltage (DOVDD) (I/O) 1.7V to 3.3V
Module PDF Please contact us.
Chip PDF Please contact us.
active array size
1280 x 800
power supply
analog: 3.0 ~ 3.6V

core: 1.5VDC + 5% (built-in regulator)
I/O
1.7 ~ 3.6V
power requirements
active: 110 mW

standby: 50 μA
temperature range
operating: -30°C to 70°C (see table 8-1)

stable image: 0°C to 50°C (see table 8-1)
output formats (10-bit)
raw RGB data
lens size
1/4"
lens chief ray angle
25° non-linear (see figure 10-2)
input clock frequency
6 ~ 27 MHz
scan mode
progressive

We could do according to customer's specific requirements. custom products are delivered fast, quality assurance, reasonable price now super-low supply:

GC0308,GC2035,GC2145,OV7251,OV7670,OV7675,OV7725,OV7740,OV9281,OV9712,OV9732,OV9655,OV9650,OV9653,OV9734

OV9750,OV2710,OV2715,OV2640,OV2643,OV2655,OV3640,OV4689,OV5640,OV5645,OV5648,OV8865,OV10633,

OV13850,IMX135,IMX219,IMX214,AR0103,AR0237,AR0238,AR0330,ASX340CS,MT9V034,NT99141 IMX385 IMX226 IMX482 OV5647cameras.

Product Details

YXF-HDF12-A98-166 (2)
YXF-HDF12-A-681 (2)
YXF-HDF7725-A32-V2-170F 1 (2)
YXF-HDF7725-A32-V2-170F 1 (3)
